Details
| Length | 1500 |
| Thickness | 2 |
| Width | 200 |
| Surface Style | Diamond Indentations |
Material Specification
| Structure | CuSn8 bronze with either grease pockets or holes |
|---|---|
| PV (N/mm² x m/s) | 2.8 max |
| Static load (N/mm²) | 120 max |
| Dynamic load (N/mm²) | 40 max |
| Sliding speed – With Grease (m/s) | 2.5 max |
| Intermittent temperature (°C) | 130 max |
| Operating temperature (°C) | -100 to 200 |
| Thermal Conductivity (W/mk) | 60 |
| Coefficient of friction | 0.08 to 0.25 |
| Hardness (HB) | 90-120 |
| Tensile strength (N/mm²) | 450 min |
| Yield point (N/mm²) | 250 min |
| Elongation (%) | 40 |
Tolerances & Fittings (Metric)
| Min | Max | Tolerance | |
|---|---|---|---|
| Thickness Tolerance | 1.94 | 2 | |
| Width Tolerance | 200 | 202 |
Frequently Asked Questions
What is WMB bronze strip used for?
WMB bronze wrapped strip is designed for slow-speed, high-load applications and is particularly suited to oscillating motion. It is used in industries such as construction, mining and quarrying, agriculture, and automotive.
What thicknesses are available?
Available thicknesses depend on the specific WMB bronze wrapped strip requirements. Contact Bowman for information on available sizes and specifications for CuSn8 strip material USA applications.
Can the strip be custom cut?
Please contact Bowman to discuss your required strip dimensions and application. Our team can advise on available options for WMB CuSn8 bearings and bronze wrapped bearing requirements.
What is CuSn8 bronze?
CuSn8 is a copper-tin bronze alloy used for bearing applications. WMB bronze wrapped strip is available as a CuSn8 strip material option for applications requiring a bronze bearing material.
How do I request a quote?
Provide your required dimensions, quantity, and application details when requesting a quote. Bowman can support customers across the USA and North America looking for WMB CuSn8 bearings or an industrial bronze wrapped bearing supplier in the US.
